PROTECTION CONTROLS ACF-RELAY / ACFRELAY (NEW)

The Protection Controls ACF relay is a plug-in component of the Protectofier Flame Safety Burner Management System used to ensure proper and safe operation of industrial burners. It can function as a check relay, flame relay, or load relay within this system. Marshall W Nelson and Associates Inc Marshall W Nelson and Associates Inc +2 Function and Use The Protection Controls ACF relay performs several critical safety functions within a burner management system, primarily concerning flame monitoring and fault detection: Marshall W Nelson and Associates Inc Marshall W Nelson and Associates Inc +3 Check Relay: Makes sure the Protectofier is functioning properly during start-up. Failure to prove a safe-start check will prevent ignition and the energizing of the fuel valves, thus ensuring safe operation. Flame Relay: Responds to the FLAME-PAK operation by energizing the circuit to the fuel valve once a flame is detected, proving the burner is lit. Load Relay: Used in multi-burner units to energize fuel valves only after all flames are proven. If any single burner loses its flame signal, the load relay de-energizes all fuel valves, preventing the accumulation of uncombusted gas. NR Relay (Non-Return): Provides a non-return of ignition after a flame failure, requiring a manual reset of the thermal circuit breaker for safety. Marshall W Nelson and Associates Inc Marshall W Nelson and Associates Inc +1 Key Specifications According to Snook & Aderton HVAC Supply and Radwell International, the relay has the following specifications: Radwell International Radwell International +1 ± 10%, 50-60 Hz (115 VAC version also available). Features: Built-in flame response light(s) and TELEFIER first-out flame indication.
